Bow Micrometer with Friction Clutch 25-50 mm HELIOS-PREISSER (0806502)

Bow Micrometer with Friction Clutch 25-50 mm HELIOS-PREISSER

Discover the pinnacle of precision and reliability with this top-tier bow micrometer from the renowned manufacturer HELIOS-PREISSER. Designed for the most demanding engineering and workshop applications where every micron is crucial. With a measuring range of 25-50 mm and a fine resolution of 0.01 mm, you will always achieve accurate and consistent results.

This micrometer is equipped with an innovative friction clutch (ratchet) that ensures constant and optimal measuring force, thereby eliminating errors caused by varying operator pressure. The locking lever then allows for secure retention of the measured value. Matte chrome-plated reading parts guarantee excellent readability even in challenging lighting conditions.

The micrometer's construction is meticulously thought out. Carbide measuring faces guarantee long life and wear resistance, while the thermally insulated body minimizes the influence of temperature changes on measurement accuracy. With this tool, you invest in quality that will be evident in every one of your projects.

Key Technical Parameters:

• Measuring Range: 25 mm - 50 mm
• Reading: 0.01 mm
• Standard: DIN 863-1
• Design: Matte chrome-plated reading parts for better visibility
• Functions: Locking lever for securing measurement, friction clutch (ratchet) for constant measuring force
• Construction: Fixed rapid traverse, carbide measuring faces for long life, thermally insulated body to minimize temperature influence
• Accuracy: Error limit ±0.004 mm (4 µm)
• Spindle: Diameter 6.5 mm, pitch 0.5 mm

HELIOS-PREISSER – a synonym for precise measuring technology you can rely on.
