Hydraulic Brinell Hardness Tester ISHB-H131 INSIZE (ISHB-H131)
- Brand: INSIZE
- Product Code: INISHB-H131
- EAN: 6928640325410
- Weight: 23,11 kg
- Availability: On request
For more information on delivery: info@k-met.com
-
Standard price: 7,583.00 EUR
Inc. Tax: 9,327.09 EUR
Hydraulic Brinell Hardness Tester ISHB-H131 by INSIZE with a measuring range of 16∼650 HBW and a test force of up to 3000 kg. Including measuring microscope, including flat and spherical anvil, and V-block.
- Conforms to ISO 6506 and ASTM E10
Technical Specification
Measuring Range
- 16-650 HBW
Test Force
- 3000 kg
Indenter
- Ø 10 mm carbide ball
Measuring Microscope
- Magnification
- 20×
- Graduation
- 0.01 mm
Max. workpiece height
- 350 mm
Max. test width
- 90 mm (from the center of the indenter)
Dimensions
- 270×225×570 mm
Weight
- 13.8 kg
Package Contents
- Hydraulic Brinell Hardness Tester ISHB-H131 INSIZE
- Flat anvil
- V-block
- Spherical anvil
- Ø 10 mm carbide ball (2 pcs)
- Brinell hardness block (2 pcs)
- Measuring microscope
Other variants
| INISHB-C161 | Hydraulic Brinell hardness tester for rings and tubes ISHB-C161 INSIZE (ISHB-C161) | On request | 6,860.00 EUR without Tax |
| INISHB-H131 | Hydraulic Brinell Hardness Tester ISHB-H131 INSIZE (ISHB-H131) | On request | 7,583.00 EUR without Tax |
| INISHB-MSA | Measuring System - Digital Brinell Measuring Magnifier 2.5-10 mm ISHB-MSA INSIZE (ISHB-MSA) | On request | 4,756.00 EUR without Tax |
| INISHB-MSA-BLOCK25 | Brinell test etalon for 2.5 mm indenter INSIZE (ISHB-MSA-BLOCK25) | On request | 84.90 EUR without Tax |
| INISHB-P101 | Portable Brinell hardness tester ISHB-P101 INSIZE (ISHB-P101) | On request | 2,514.00 EUR without Tax |
